• Externally biased condenser
• Cardioid or Omni polar pattern using included interchangable capsules
• Gold sputtered 1/2” capsule
• Three position PAD - 0dB, -10dB and -20dB
• Three position High-Pass Filter - flat, 75Hz and 150Hz
• Surface mount circuitry
• Low noise
• Available as Certified Matched Pair

Active Electronics
JFET impedance converter with bipolar output buffer

Capsule
0.50"

Polar Pattern

Address Type
End

Frequency Range
20Hz - 20kHz

Output Impedance
100Ω

Maximum SPL
136dBSPL

Maximum Output Level
8.0mV (@ 1kHz, 1% THD into 1KΩ load)

Sensitivity
-38.0dB re 1 Volt/Pascal (12.60mV @ 94 dB SPL) +/- 2 dB @ 1kHz

Equivalent Noise Level (A-weighted)
15dBA

Power Options

Weight
110.00g

Dimensions
145.00mmH x 20.00mmW x 20.00mmD

Output
