Specifications
Input Sensitivity: rated power 4ohm0dBu 0.775V
Distortion THD: 1kHz @ rated power 0.01-0.02%
Frequency Response: 20Hz – 20kHz (+0/-0.5dB)
Signal to Noise Ratio: rated power 4ohm 100dB unweighted
Input Filter: 3rd order 18dB/oct 35Hz
Crossover: selectable 100/150Hz 3rd order filter
Cooling: Twin variable speed fans, back to front airflow
Protection: Full short circuit, open circuit, thermal, ultrasonic and RF protection
Power Requirements: 230V +/-10% 50/60Hz
Input Connections: Combination XLR and Jack, Male XLR link socket
Output Connections: 4 pole industry standard sockets
Both Channel @ 8ohms RMS: 450watts
Both Channel @ 4ohms RMS: 750watts
Both Channel @ 2ohms RMS: 990watts
Bridged @ 8ohms RMS: 1500watts
Bridged @ 4ohms RMS: 1950watts
Output Circuit: AB+H(2)
Power Consuption @230V 1/power: 7A
