• 2 x 31 band 1 / 3 octave graphic equaliser
• Input trim and signal / clip led indication
• Switchable cut / boost range and 40Hz high pass filter
• Bypass switch for quick comparison
• 19″ 2U

Centre frequencies: SRQ30 (63Hz-16kHz), SRQ62 (20Hz-20kHz), SRQ62L (20Hz-20kHz)
Frequency response: 10Hz – 55kHz
Frequency cut/boost: 12dB
Distortion: 0.004%
Signal to noise ratio: 98dB
Gain cut/boost: selectable 15dB / 6dB
Input trim range: infinity to +6dB
Maximum input level: +23dBu balnced, +20dBu unbalanced
Maximum output level: +23dBu balnced, +20dBu unbalanced
Input impedance: 20k ohms balanced, 10k ohms unbalanced
Output impedance: <150 ohms
Hi pass filter: SRQ62 (40Hz @ 12dB/oct), SRQ62L (12-285Hz @12dB/oct)
Metering: 2x M10 hanging points
Meter calibration: 2x M10 hanging points
Connections: 2x M10 hanging points
Fader travel: 2x M10 hanging points
Power requirements: 2x M10 hanging points
Power consumption: 2x M10 hanging points
Dimension W*D*H: 483×186 x 44(SRQ30), 88(SRQ62), 132(SRQ62L) mm
Weight: 2.5kg, 3.5kg, 4.5kg
