SX-235
1000Wx2 channels, Power Amplifier
Brand: Studio Master

Both Channel @ 8ohms RMS: 580watts
Both Channel @ 4ohms RMS: 1000watts
Bridged @ 8ohms RMS: 2000watts

Power Consuption @230V 1/3 power: 7.9A

Dimensions: 483mm x 89mm x 435mm
Weight (net/shipping): 13.4kg / 18kg



Input Sensitivity: rated power 4ohm0dBu 0.775V
Distortion THD: 1kHz @ rated power 0.03%
Frequency Response: 10 – 31kHz (+0/-1dB)
Signal to Noise Ratio: 95-100dB unweighted
Crosstalk: 95-100dB unweighted
Input Impedance: 10k ohm unbalanced, 20k ohm balanced
Damping Factor: 250
Voltage Gain: 37-40dB
Input Filter: switchable 35Hz
Input Modes: stereo, parallel and bridged
Cooling: Variable speed fan
Protection: Full short circuit, open circuit, thermal, RF
Output circuit type: Class AB + H 2 step high efficiency output
Power Requirements: 110V or 230V +/-10% 50/60Hz
Input Connections: Combination XLR, Male XLR link socket
output Connections: 4 pole industry standard sockets & binding posts
