• Large diaphragm 1” gold-sputtered capsule
• Cardioid polar pattern
• True condenser (externally biased)
• Full frequency response
• Ultra low noise
• High strength welded and heat-treated mesh head
• Internal capsule shock mounting

Acoustic Principle
Pressure Gradient

Active Electronics
Unity-gain closed-loop impedance converter; JFET input with bipolar buffering

Capsule
1.00"

Polar Pattern

Address Type
Side

Frequency Range
20Hz - 20kHz

Output Impedance
100Ω

Maximum SPL
140dBSPL

Maximum Output Level
13.0mV (@ 1kHz, 1% THD into 1KΩ load)

Sensitivity
-36.0dB re 1 Volt/Pascal (16.00mV @ 94 dB SPL) +/- 2 dB @ 1kHz

Equivalent Noise Level (A-weighted)
6dBA

Power Options

Weight
682.00g

Dimensions
209.00mmH x 54.00mmW x 54.00mmD

Output
