- VHF frequency band and 42 frequency groups for interence-free reception
- Multilevel high frequency and mid frequency narrowband filter for minimum signal interence
- Unique ALC circuitry for avoiding distortion when volume is high
- Pure quartz oscillator circuitry for stable frequency
- Aduio companding technique for reducing the nosie and enlarging the dynamic range
- Effective feedback control circuitry
- Low power consumption design
- LED power indicator for low battery warining on handheld microphone transmitter
- Circuit controlled switching nosie elimination
- Independent unbalanced and mixed output
- Rugged and durable handheld microphone design
-
• Frequency Band:VHF-H
• Frequency Response: 80Hz-15kHz
• Frequency Stability: ±0.005%
• S/N Ratio: >70dB
• Total Harmonic Distortion: ＜0.5% (at 1kHz)
• Number of Channels: 2 Channels
• Operating Range: 50m in Open Area
Receiver
• Squelch Control:Noise-Lock
• Receiving Sensitivity: -80dBm
• False Image Interfere Rate: ≥80dB
• Receiver Power Supply: DC 12V/300mA
• Output Type: Separate or Mixed Output
Transmitter
• Frequency Deviation: ±18kHz
• Frequency Stability: ±0.005%
• Modulation Mode:FM
• Transmit Power: ≤10mW
• Transmitter Power Supply: 9V layer-built battery for handheld microphones AA 1.5V x 2 for body-pack transmitters
