- Large diaphragm 1” gold-sputtered capsule
- Class “A” valve circuitry
- Hand selected and graded 6922 twin-triode valve
- Dedicated power supply
- Internal capsule shock mounting
- High level of RF rejection
- Ultra low noise
- Wide dynamic range
- High strength heat treated steel mesh head
Acoustic Principle
Pressure Gradient
Active Electronics
Valve/tube impedance converter with bipolar output buffer
Capsule
1.00"
Polar Pattern
Address Type
Side
Frequency Range
20Hz - 20kHz
Output Impedance
200Ω
Maximum SPL
158dBSPL
Maximum Output Level
29.0mV (@ 1kHz, 1% THD into 1KΩ load)
Sensitivity
-38.0dB re 1 Volt/Pascal (25.00mV @ 94 dB SPL) +/- 2 dB @ 1kHz
Equivalent Noise Level (A-weighted)
12dBA
Power Options
Weight
760.00g
Dimensions
208.00mmH x 55.00mmW x 55.00mmD
Output
